Outdoor PoE Extender
Description:
PoE-EX2001H-90WP Power over Ethernet(PoE)Extender greatlysimplifies the deployment of lP cameras.wireless access points and equipment morethan 100m from network points.
Features:
Outdoor Waterproof Gigabit PoE Extender
Compatible lEEE 802.3bt (4Pairs 90w)
Compatible lEEE 802.3af and lEEE 802.3at
Extends the range of PoE and Ethernet anadditional 100meters
No additional power supply is required
Full-rate network throughout the wholeextended distance
Wall-Mountable design
Easy plug-and-play installation
Surge protection (6KV)for power port anddata ports
Specifications:
| Item | Description |
| No.of channals | 1(PoE IN) into 1(PoE OUT) |
| Pass Through Data Rates | 10/100/1000Mbps half/full duplex |
| Power over Ethernet Input | Compatible standards: IEEE 802.3af (PoE), IEEE 802.3at (PoE+), IEEE802.3bt 4Pairs(90W) Pin Assignment and Polarity: Both 1/2 , 3/6 and 4/5 , 7/8 |
| Power over Ethernet Output | Compatible standards: IEEE 802.3af (PoE), IEEE 802.3at (PoE+), IEEE802.3bt 4Pairs(90W) Pin Assignment and Polarity: 1/2 (+), 3/6 (-) and 4/5 (+), 7/8 (-) Note: The actual output power depends on the input power. |
| Connectors | Waterproof RJ45, EIA 568A and 568B |
| Network Cables | Outdoor type shielded category 5 (or higher) |
| Dimensions | 185 x 45 x 45 mm |
| Mounting | Wall of shelf |
| Environment | Indoor or Outdoor |
| Environmental Conditions | Operating Ambient Temperature: -25 to 55℃ Operating Humidity: Maximum 90%, Non-condensing Storage Temperature: -30 to 70℃ Storage Humidity: Maximum 95%，Non-condensing |
| Regulatory Compliance | IEEE 802.3af (PoE) IEEE 802.3at (PoE+) IEEE 802.3bt(PoE++) |
