DetailFile
16 Port 10 / 100Base - TX (PoE)with 1 Gigabit Combo Port +1 Gigabit RJ-45 Ethernet Switch
Description:
PoE-2018-16P-250W is 16 Port 10/100Base-TX with 2 Gigabit Combo Port and 16 PoE Ethernet Switch
Features:
Conforms to IEEE802.3,1EEE 802.3u,IEEE 802.3ab,IEEE802.3af,IEEE802.3at
Provides 16 10/100Base-TX ports and 2 Gigabit Combo
Provides 16 PoE injector and 250W Built-in power supply
High back-plane bandwidth 7.2Gbps for 16+2G
IEEE802.3x Flow control
EMl standards complies with FCC, CE class B, UL
Specifications:
| Item | Description | ||
Power | Power supply | Built-in power supply | |
| Voltage Range | AC100~240V | ||
| Consumption | 250W for 16 PoE | ||
| Ethernet | Speed | 1~16 Port: 10/100Mbps G1 -G2.Gigabit Combo | |
Transmission Distance | 100Meter (328 ft) for RJ 45 2Km 20Km for SFP Port The optical module is optional | ||
| Network Switch | Ethernet Standard | IEEE 802.3/802.3u/802.3ab/802.3af/at | |
| Switching capacity | 7.2G | ||
| Transfer Rate | 14,880 pps for 10Mbps 148,800 pps for 100Mbps 148,8000 pps for 1000Mbps | ||
| MAC Address | 4K MAC address table | ||
| LINK/ACT | On | Green | The port is connecting |
| Blinks | - | The port is receiving or transmitting data. | |
| Off | - | The port is not linked successfully with the device | |
| POE | On | Orange | PD is connected |
| Off | - | No PD is connected or power forwarding fails | |
| PoEpin assignmnet | V+( Rj45 Pin 1, 2), V-(Rj45 Pin 3,6) | ||
| Environment | Working Temperature | 0~40℃ | |
| Storage Temperature | -40~70℃ | ||
| Humidity Non condesing | 0~90 % | ||
| Mechanical | Dimension | 440 x 200 x 44mm | |
| Color | Gray | ||
Q1: Are you a factory?
A: Yes, we are a POE Switches & Power Supply factory.
Q2: How many years is your products warranty?
A: Regular 1 year.
Q3: Do you accept OEM?
A: Sure, we accept OEM.
Q4: What is your delivery time and payment term?
A: We will reply the specific delivery time according to your order qty. Usually 7~10days. We accept T/T, Paypal and Western Union payment method.
Q5: Do you have any certification?
A: Yes, we have UL, FCC, CE, RoHS right now. If you need other certifications in large quantities order, we can apply it for you.
