DC12V16A 8CH PTC FUSE 4K Power Supply Box

share
WeChat
Sina Weibo
QQ
copy Link
Facebook
X
LinkedIn
Brand CENTROPOWER
Model PS-DC16A08HD-4DK
Color White and Blue
Spec DC12V16A 8CH PTC FUSE 4K Power Supply Box
0755-23200933
DetailFile

DC12V16A 8CH PTC FUSE 4K Power Supply Box

Feature:

  • Wall type royal bluebaking finished shell, easy installation.

  • Universal AC InputRange. 110V-220VAC, 47-63Hz

  • DC outputs areregulated and filtered.

  • Individual voltage adjustable for each output, 11-15V.

  • Shortcircuit /OverVoltage/Over Current/Over TempProtection.

  • Individual tubefuse, PTC output protection for eachport

  • External LEDindicator for each output

  • 100% full loadburn-in test, High efficiency, Long service life, high reliability


Specifications:

ItemDescription
Input VoltageAC110 -220V
Output Voltage

DC 12V 16A 8Channel

Efficiency≥82%
Fuse TypePTC Fuse
Fuse Rating2A
Operating Temperature-10~50℃
Safety StandardsIEC/EN/UL/CSA 60950GB4943
Withstand VoltageIP-OP: 1.5KV, IP-FG:1.5KV, OP-FG 0.5KVAC 30S
EMC Anti-interferenceEN61000-4-2,3,4,5,6,8,11;EN61000-3-2,3; EN55022
ColorRoyal Blue
ApplicationCCTV Camera, IPCamera, PTZ, IR Illuminator, Video process,DVR, Access Control , etc.
CertificationCE,RoHS, FCC,UL,cULetc.








Q1: Are you a factory?
A: Yes, we are a POE Switches & Power Supply factory.
Q2: How many years is your products warranty?
A: Regular 1 year.
Q3: Do you accept OEM?
A: Sure, we accept OEM.
Q4: What is your delivery time and payment term?
A: We will reply the specific delivery time according to your order qty. Usually 7~10days. We accept T/T, Paypal and Western Union payment method.
Q5: Do you have any certification?
A: Yes, we have UL, FCC, CE, RoHS right now. If you need other certifications in large quantities order, we can apply it for you.
